1N4685-1 ZENER DIODES

The 1N4678-1 thru 1N4717-1 series of 0.5 watt Zener voltage regulators provides a selection from 1.8 to 43 volts in standard 5% tolerances as well as tighter tolerances. These axialleaded glass DO-35 Zeners are available with an internal metallurgical bond similar to military requirements for simila.

1N4685-1 Features

* JEDEC registered 1N4678 thru 1N4717 series.

* Internal metallurgical bond.

* Tighter voltage tolerances of 2% and 1% are available.

* Up-screening available in reference to MIL-PRF-19500. (See part nomenclature for all available options).

* RoHS compliant de

1N4685-1 Datasheet (160.92 KB)
