1PMT4106, 1PMT4614 - Powermite Low Noise 1 Watt Zener Diodes

Microsemi

The 1PMT4106 by Microsemi is a Powermite Low Noise 1 Watt Zener Diodes. Below is the official datasheet preview.

Datasheet Details

Part number	1PMT4106, 1PMT4614
Manufacturer	Microsemi
File Size	471.94 KB
Description	Powermite Low Noise 1 Watt Zener Diodes
Datasheet	1PMT4614-Microsemi.pdf
Note	This datasheet PDF includes multiple part numbers: 1PMT4106, 1PMT4614. Please refer to the document for exact specifications by model.
Additional preview pages of the 1PMT4106 datasheet.

This Microsemi Powermite surface mount low noise Zener package series provides a higher power handling capability that are also RoHS compliant.

include a full-metallic bottom that eliminates the possibility of solder flux entrapment during assembly, and a unique locking tab acts as an efficient heat path from die to mounting plane for external heat sinking with very low thermal resistance junction to case (bottom). Its innovative design makes this device ideal for use with automatic insertion equipment. Important: For the latest information, visit our website http://www. microsemi. com.
