CDLL4110-1, CDLL4614-1, 500mW Metallurgically Bonded Glass Surface Mount Zener Diodes

1N4614UR-1 * 1N4627UR-1e3, 1N4099UR-1 * 1N4135UR-1e3 Available on commercial versions 500 mW Metallurgically Bonded Glass Surface Mo.
The 1N4099UR-1 through 1N4135UR-1 and 1N4614UR-1 through 1N4627UR-1 series are 500 mW, Zener voltage regulators in the surface mount, glass DO-213AA.

CDLL4614-1-Microsemi.pdf

CDLL4110-1 Datasheet Preview — This datasheet PDF includes multiple part numbers: CDLL4110-1, CDLL4614-1. Please refer to the document for exact specifications by model.

Datasheet Details

Part number:

CDLL4110-1, CDLL4614-1

Manufacturer:

Microsemi ↗

File Size:

291.89 KB

Description:

500mW Metallurgically Bonded Glass Surface Mount Zener Diodes

Note:

This datasheet PDF includes multiple part numbers: CDLL4110-1, CDLL4614-1.
Please refer to the document for exact specifications by model.

Features

* Surface mount equivalent to JEDEC registered 1N4099 through 1N4135 and 1N4614 through 1N4627 series.
* Internal metallurgical bond.
* Max noise density 40 μV / √Hz for 6.8 V and up. Falls quickly to 1 μV / √Hz at lower voltages.
* JAN, JANTX, JANTXV and JANS qualifi
