XE1000-BD Datasheet, Divider, Mimix Broadband

XE1000-BD Features

  • Divider Divide-by-Four +5.0 dBm Output Power -30 dBc Fundamental Leakage Single-ended or Differential Input & Output 100% On-Wafer, DC and Output Power Testing 100% Visual Inspection to MIL-STD

PDF File Details

Part number:

XE1000-BD

Manufacturer:

Mimix Broadband

File Size:

188.64kb

Download:

📄 Datasheet

Description:

Gaas mmic frequency divider. Mimix Broadband's 2.0-16.0 GHz GaAs MMIC freqency divider is an ECL (Emitter Coupled Logic) static frequency divider (divide-by-four)

Datasheet Preview: XE1000-BD 📥 Download PDF (188.64kb)
Page 2 of XE1000-BD Page 3 of XE1000-BD

XE1000-BD Application

  • Applications Absolute Maximum Ratings Supply Voltage (Vcc) Supply Current (Icc) Input Power (Pin) Storage Temperature (Tstg) Operating Temperature
