MCA1-60
Features
- -
- -
- -
- -
- - wide bandwidth, 1600 to 6000 MHz useable to 8 GHz IF, DC to 2000 MHz LTCC double balanced mixer low cost low profile, 0.08" PCN defense & weather radar WCDMA defense munications
MCA1-60+
1600 to 6000 MHz
CASE STYLE: DZ885 PRICE: $7.95 ea. QTY (10-49) (Patent pending)
Applications
+ Ro HS pliant in accordance with EU Directive (2002/95/EC)
The +suffix has been added in order to identify Ro HS pliance. There has been no change to the model's material, form, fit, or function. See our web site for Ro HS pliance methodologies and qualifications.
Mixer Electrical Specifications (TAMB=-55°C to 100°C)
MODEL NO. FREQUENCY (MHz)
LO/RF f L- f U MCA1-60+ 1600-4400 4400-6000 IF DC-2000 DC-2000
CONVERSION LOSS (d B) _ x 6.3 6.2 σ 0.2 0.3 Max. 8.3- 8.5-
LO-RF ISOLATION (d B)
Typ. Min. 32 23 20 17
LO-IF ISOLATION (d B)
Typ. Min. 17 18
- -
IP3@ center band Typ. (d Bm)
9 8
E FACTOR
0.2 0.1
1d B pr.: +1 d Bm typ. E= [IP3(d Bm)-LO Power(d Bm)]/10
- Conversion loss at 30 MHz...
