ZFL-750+ Datasheet, Amplifier, Mini-Circuits

ZFL-750+ Features

• Amplifier
• wideband, 0.2 to 750 MHz
• rugged shielded case
• low noise figure, 6 dB typ.
• protected by US Patent, 6,943,629 Applications
• VHF/UHF

PDF File Details

Part number:

ZFL-750+

Manufacturer:

Mini-Circuits

File Size:

172.05kb

Download:

📄 Datasheet

Description:

Amplifier.

ZFL-750+ Application

• Applications
• VHF/UHF
• lab use
• instrumentation MODEL NO. FREQUENCY (MHz) fL fU ZFL-750+ 0.2 750 Amplifier Electric
