FU-632SEA-V61MxxF - EAM/DFB-LD MODULE

This page provides the datasheet information for the FU-632SEA-V61MxxF, a member of the FU-632SEA-V61M5F EAM/DFB-LD MODULE family.

Datasheet Summary

Description

Module type FU-632SEA-x61MyyF is an electro-aborption modulator integrated with 1.55μm DFB-LD module with single mode optical fiber.

This module is suitable to a light source in 2.5Gb/s digital optical communication systems where the distance is more than 640km.

Features

  • Input impedance is 50Ω.
  • Electroabsorption Modulator integrated Multi quantum wells (MQW) DFB Laser Diode.
  • Emission wavelength is in full C band.
  • Single mode optical fiber pig-tail.
  • Built-in optical isolator.
  • Built-in thermal electric cooler.
  • Butterfly package.
  • With photodiode for optical output monitor.
  • RoHS (2002/95/EC) complianｔ.

📥 Download Datasheet

Datasheet preview – FU-632SEA-V61MxxF

Datasheet Details

Part number FU-632SEA-V61MxxF
Manufacturer Mitsubishi Electric
File Size 238.86 KB
Description EAM/DFB-LD MODULE
Datasheet download datasheet FU-632SEA-V61MxxF Datasheet
Additional preview pages of the FU-632SEA-V61MxxF datasheet.

📁 Similar Datasheet

Other Datasheets by Mitsubishi Electric

Full PDF Text Transcription

Click to expand full text
MAY06 (1/6) MITSUBISHI (OPTICAL DEVICES) FU-632SEA-x61MyyF 1.55 μm EAM/DFB-LD MODULE WITH SINGLEMODE FIBER PIGTAIL DESCRIPTION Module type FU-632SEA-x61MyyF is an electro-aborption modulator integrated with 1.55μm DFB-LD module with single mode optical fiber. This module is suitable to a light source in 2.5Gb/s digital optical communication systems where the distance is more than 640km. This module is prepared in accordance with ITU-T recommendation wavelength channel plan for DenseWDM transmission.
