M30624FGMGP, M306 Datasheet - Mitsubishi

M30624FGMGP SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER

SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Description The M16C/62 group of single-chip microcomputers are built using the high-performance silicon gate CMOS process using a M16C/60 Series CPU core and are packaged in a 100-pin plastic molded QFP. These single-chip microcomputers operate using sophisti.

M30624FGMGP Features

* Memory capacity ROM (See Figure 1.1.4. ROM Expansion) RAM 3K to 20K bytes

* Shortest instruction execution time 62.5ns (f(XIN)=16MHZ, VCC=5V) 100ns (f(XIN)=10MHZ, VCC=3V, with software one-wait) : Mask ROM, flash memory 5V version 142.9ns (f(XIN)=7MHZ, VCC=3V, with software one-w

M306-24FG.pdf

This datasheet PDF includes multiple part numbers: M30624FGMGP, M306. Please refer to the document for exact specifications by model.
M30624FGMGP Datasheet Preview Page 2 M30624FGMGP Datasheet Preview Page 3

Datasheet Details

Part number:

M30624FGMGP, M306

Manufacturer:

Mitsubishi

File Size:

3.48 MB

Description:

Single-chip 16-bit cmos microcomputer.

Note:

This datasheet PDF includes multiple part numbers: M30624FGMGP, M306.
Please refer to the document for exact specifications by model.
