A-41662-B02Y208

3.96mm (.156) Pitch KK Header

A-41662-B02Y208 General Description

0416620001 Active 3.96mm (.156") Pitch KK® Header, Breakaway, Right Angle, 2 Circuits, 0.38µm (15µ") Gold (Au) Selective Plating Documents: 3D Model Packaging Specification (PDF) Drawing (PDF) Product Specification PS-08-50 (PDF) RoHS Certificate of Compliance (PDF) Series image - Reference only.

A-41662-B02Y208 Datasheet (189.31 KB)

Preview of A-41662-B02Y208 PDF

Datasheet Details

Part number:

A-41662-B02Y208

Manufacturer:

Molex Electronics

File Size:

189.31 KB

Description:

3.96mm (.156) pitch kk header.
