53748-0504
FEATURES
AND SPECIFICATIONS s s s s s s
Features and Benefits Stacking height: 3.0mm Sizes 20 to 80 circuits Locking feature provides secure mating High temperature housing Durable blade on beam contact interface Anti-flux design
Electrical Voltage: 50V Current: 0.5A Contact Resistance: 50mΩ max. Dielectric Withstanding Voltage: 500V AC Insulation Resistance: 100 MΩ min. Physical Housing: White glass-filled LCP plastic, UL 94V-0 Contact: Brass Plating: Gold over Nickel Operating Temperature: -40 to +105˚C
0.50mm (.020") Pitch Board-to-Board Plug 53748 SMT, Dual Row Vertical Stacking
Reference Information Packaging: Embossed tape Mates With: 52991 Designed In: Millimeters
Mating Dimensions 53748
- 52991 H=3.0mm W=5.4mm
CATALOG DRAWING (FOR REFERENCE ONLY)
Data Shee
.
ORDERING INFORMATION AND DIMENSIONS
Circuits 20 30 40 50 60 70 80 Order No. With Vacuum Pick-up Tape Without 53748-0204 53748-0304 53748-0404 53748-0504 53748-0604 53748-0704 Dimension Vacuum Pick-up Tape...
