MC68307 - Technical Summary Integrated Multiple-Bus Processor

Product Overview

Motorola

📥 Download Datasheet

MC68307 Technical Summary Integrated Multiple-Bus Processor by Motorola - Datasheet Preview — Datasheet preview – MC68307

Datasheet Details

Part number	MC68307
Manufacturer	Motorola
File Size	354.89 KB
Description	Technical Summary Integrated Multiple-Bus Processor
Datasheet	MC68307 Datasheet
Additional preview pages of the MC68307 datasheet.

Product details

Features

of the MC68307 include:.
Static EC000 Core Processor.
Identical to MC68EC000 Microprocessor.
Full compatibility with MC68000 and MC68EC000.
24-bit address bus, for 16-Mbyte off-chip address space.
16-bit on-chip data bus for MC68000 bus operations.
Static design allows processor clock to be stopped providing dramatic power savings.
2.4 MIPS performance at 16.67-MHz processor clock.
External M68000 Bus Interface with Dynamic Bu.
