UF2001

The UF2001 is Ultra Fast Rectifier designed by Multicomp.

Product Overview

Multicomp

📥 Download Datasheet

UF2001 Ultra Fast Rectifier by Multicomp - Datasheet Preview — Datasheet preview – UF2001

Datasheet Details

Part number	UF2001
Manufacturer	Multicomp
File Size	374.27 KB
Description	Ultra Fast Rectifier
Datasheet	UF2001-Multicomp.pdf
Additional preview pages of the UF2001 datasheet.

Product details

Features

Dimensions : Inches (Millimetres).
Diffused junction.
Ultra fast switching for high efficiency.
Low reverse leakage current.
Low forward voltage drop.
High current capability.
Plastic material Mechanical Data: Case Polarity Weight Mounting position : JEDEC DO-15 moulded plastic : Colour band denotes cathode : 0.015 ounces, 0.4 grams : Any Maximum Ratings and Electrical Characteristics: Rating at 25°C ambient temperature unless otherwi.
