MTU1, Isolated 1W Single Output SM DC/DC Converters

www.murata-ps.com MTU1 Series Isolated 1W Single Output SM DC/DC Converters SELECTION GUIDE Efﬁciency (Min.) Input Current at Full Load Efﬁciency (Typ.) Load Regulation (Typ.) Load Regulation (Max) Output Current Nominal Input Voltage Ripple & Noise (Typ.)3 Ripple & Noise (Max.)3 Isolation Capacitance pF 19 20 21 22 22 31 40 35 Output Voltage Order Code1 V MTU1S0505MC MTU1S0509MC MTU1S0512MC MTU1S0515MC MTU1S1205MC MTU1S1209MC MTU1S1212MC MTU1S1215MC 5 5 5 5 12 12 12 12 V 5 9 12 15 5 9

MTU1 Features

* Patent Pending Footprint over pins 0.69cm2 Single isolated output 1kVDC Isolation Efﬁciency up to 88% (Typ.) MSL Level 1 Power density 1.71W/cm3 Wide temperature performance at full 1 Watt load,

* 40°C to 85°C UL 94V-0 Package material 5V & 12V Input 5V, 9V, 12V & 15V output Toroidal magnetic
