CS5842

LCD Panel Timing Controller

CS5842 Features

* (continued)

* Correspondent to control timing & specific resolution for different Driver IC by changing a Mask: 1. can vary the pulse width & starting position of LP signal and POL signal polarity position changed along with LP signal 2. can vary the pulse width & starting position of CLKV s

CS5842 General Description

w w CS5842 is a TFT-LCD timing controller, which is applicable to 8-bit data XGA (1024
*768), SXGA (1280
*1024). CS5842 can update the response timing for display mode of XGA and SXGA automatically. CS5842 provides a selectable polarity check function to inverse output data for EMI reducing.

CS5842 Datasheet (219.25 KB)

Preview of CS5842 PDF

Datasheet Details

Part number:

CS5842

Manufacturer:

Myson Century

File Size:

219.25 KB

Description:

Lcd panel timing controller.
