ACV31012
FEATURES
- Low profile: 22.5 mm(L)×15 mm(W)×15.7 mm(H) .886 inch(L)×.591 inch(W)×.618 inch(H)
- Low temperature rise Terminal temperature has been reduced pared with using our conventional product
- Low sound pressure level Noise level has been reduced approx.10d B pared with using our conventional product.
- Wide line-up Micro ISO/Micro 280 terminal types and resistor and diode inside type, PCB terminal type (Micro 280 only).
- Plastic sealed type Plastically sealed for automatic cleaning.
CV-RELAYS
Micro ISO 1c type
Micro ISO 1a type
Micro 280 plug-in type Micro 280 PCB type
SPECIFICATIONS
Contact
Arrangement Contact material Initial contact resistance, max. (By voltage drop 6 V DC 1 A) Initial contact voltage drop, max. Nominal switching capacity Max. carrying current (14 V DC, at 85°C 185°F) Mechanical (at 120 cpm) 1 Form A Silver alloy 50mΩ N.O.: 0.2 V (at 20 A switching) N.C.: 0.5 V (at 10 A switching) N.O.: 20 A 14 V DC N.C.: 10 A 14 V DC N.O.: 20 A N.C.: 10 A Min. 106 Min....
