NE500100 - C-Band Medium Power GaAs MESFET

NE500100 Description

C-BAND MEDIUM POWER GaAs MESFET NE8500100 NE8500199 .
The NE8500199 is a medium power GaAs MESFET designed for up to a 1W output stage or as a driver for higher power devices.

NE500100 Features

* HIGH OUTPUT POWER: 1 W
* HIGH LINEAR GAIN: 9.0 dB
* HIGH EFFICIENCY: 37% (PAE)
* INDUSTRY STANDARD PACKAGING
* THIS DEVICE IS ALSO AVAILABLE AS A TWO-CELL CHIP: NE8500100 ABSOLUTE MAXIMUM RATINGS1 (TC = 25 °C unless otherwise noted) SYMBOLS VDS VGD VGS IDS

📥 Download Datasheet

Preview of NE500100 PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Details

Part number
NE500100
Manufacturer
NEC Electronics
File Size
86.97 KB
Datasheet
NE500100_NECElectronics.pdf
Description
C-Band Medium Power GaAs MESFET
