NTE8242 - Thermal Cutoff (Thermal Fuse)

Description

Nineteen Thermal Cut

offs (also known as Thermal Fuses) are now included in the NTE product line.

RESETTABLE temperature sensitive devices designed to prevent appliances and electronic equipment from overheating.

NTE thermal cutoffs are UL and CSA listed.

Features

  • Maximum Current Rating: 15 Amps 3.220 (81.78).
  • Typical Opening Temperature Tolerance: +0°C,.
  • 4°C.
  • 18 Gauge Solid Copper Wire 1.380 .457 (11.6) Ref 1.383 (35.0) (35.1).
  • Full 1 1/3 ” leads to fit all replacement configurations Case End Epoxy End.
  • All types meet the requirements of Underwriters Laboratories Specifications and CSA.
  • Each device comes packaged with 2 crimp splices for solderless connection (Poly.
  • bag or Carton pac.

📥 Download Datasheet

Datasheet preview – NTE8242

Datasheet Details

Part number NTE8242
Manufacturer NTE Electronics
File Size 20.85 KB
Description Thermal Cutoff (Thermal Fuse)
Datasheet download datasheet NTE8242 Datasheet
Additional preview pages of the NTE8242 datasheet.

📁 Similar Datasheet

  • NTE862 - Integrated Circuit Audio Power Amplifier (NTE)
  • NTE867 - Integrated Circuit BiMOS Input Op-Amp (NTE)
  • NTE88 - Silicon Complementary Transistors (NTE)
  • NTE-247 - Silicon Complementary Transistors Darlington Power Amplifier (NTE)
  • NTE0303MC - DC/DC Converters (Murata)
  • NTE0305MC - DC/DC Converters (Murata)
  • NTE0309MC - DC/DC Converters (Murata)
  • NTE0312MC - DC/DC Converters (Murata)
  • NTE0315MC - DC/DC Converters (Murata)
  • NTE0503MC - DC/DC Converters (Murata)
Other Datasheets by NTE Electronics
  • NTE824 - Integrated Circuit Low Noise Dual Preamplifier
  • NTE821 - Integrated Circuit TV Chroma Demodulator
  • NTE8212 - Integrated Circuit Schottky / 8-Bit Input/Output Port
  • NTE823 - Integrated Circuit Low Voltage Audio Amplifier
  • NTE825 - Integrated Circuit Battery Operated Audio Amp
  • NTE826 - Integrated Circuit TV Sound System / 2W
  • NTE828 - Integrated Circuit Audio Power Amp / 1.5W
  • NTE829 - Integrated Circuit Electronics Attenuator / 90dB @ 1kHz

Full PDF Text Transcription

Click to expand full text
NTE8070 thru NTE8242 Thermal Cutoff (Thermal Fuse) Description: Nineteen Thermal Cut–offs (also known as Thermal Fuses) are now included in the NTE product line. They are miniature, NON–RESETTABLE temperature sensitive devices designed to prevent appliances and electronic equipment from overheating. NTE thermal cutoffs are UL and CSA listed. Literally thousands of different applications have been devised for thermal–cutoffs, thus providing a large replacement market.
