74HC4049 Datasheet, Shifter, NXP

74HC4049 Features

• Shifter
• Low-power dissipation
• Complies with JEDEC standard no. 7A
• ESD protection:
• HBM JESD22-A114F exceeds 2 000 V
• MM JESD22-A115-A exceeds 200

PDF File Details

Part number:

74HC4049

Manufacturer:

NXP ↗

File Size:

700.37kb

Download:

📄 Datasheet

Description:

Hex inverting high-to-low level shifter. The 74HC4049 is a hex inverter with over-voltage tolerant inputs. Inputs are overvoltage tolerant to 15 V. This enables the device to

74HC4049 Application

• Applications 2. Features and benefits
• Low-power dissipation
• Complies with JEDEC standard no. 7A
• ESD protection:
