ACT108W-600E
www.DataSheet4U.com
AC Thyristor power switch
Rev. 02 — 26 May 2009 Product data sheet
1. Product profile
1.1 General description
AC Thyristor power switch in a SOT223 surface-mountable plastic package
1.2 Features and benefits
Common terminal on mounting base enables shared cooling pad Exclusive negative gate triggering Full cycle AC conduction High over-voltage withstand capability Remote gate separates the gate driver from the effects of the load current Surface-mountable plastic package Very high noise immunity
1.3 Applications
Contactors, circuit breakers, valves, dispensers and door locks Fan motor circuits Lower-power highly inductive, resistive and safety loads Pump motor circuits
1.4 Quick reference data
Table 1.
