MMA8104EG

Digital X-Axis or Z-Axis Accelerometer

MMA8104EG Features

* Available in 20g, 40g, 150g, and 250g (MMA82XXEG, X-axis), 50g and 100g (MMA82XXTEG, X-axis) and 40g, 100g, 150g, and 250g (MMA81XXEG, Z-axis). Additional g-ranges may be available upon request

* 80 customer-accessible OTP bits

* 10-bit digital data output from 8 to 10 bit

MMA8104EG General Description

MMA81XXEG/MMA82XXEG/MMA82XXTEG family is a satellite accelerometer which is comprised of a single axis, variable capacitance sensing element with a single channel interface IC. The interface IC converts the analog signal to a digital format which is transmitted in accordance with the DSI-2.0 specifi.

MMA8104EG Datasheet (559.13 KB)

Preview of MMA8104EG PDF

Datasheet Details

Part number:

MMA8104EG

Manufacturer:

NXP ↗

File Size:

559.13 KB

Description:

Digital x-axis or z-axis accelerometer.
Freescale Semiconductor Technical Data Digital X-Axis or Z-Axis Accelerometer The MMA81XXEG (Z-axis) and MMA82XXEG/MMA82XXTEG (X-axis) are members of .
