PBTR2040CTB Datasheet - NXP

PBTR2040CTB_PhilipsSemiconductors.pdf

Preview of PBTR2040CTB PDF
PBTR2040CTB Datasheet Preview Page 2 PBTR2040CTB Datasheet Preview Page 3

Datasheet Details

Part number:

PBTR2040CTB

Manufacturer:

NXP ↗

File Size:

42.37 KB

Description:

Rectifier diodes schottky barrier.

PBTR2040CTB, Rectifier diodes Schottky barrier

Dual, common cathode schottky rectifier diodes in a conventional leaded plastic package and a surface mounting plastic package.

Intended for use as output rectifiers in low voltage, high frequency switched mode power supplies.

The PBYR2045CT series is supplied in the SOT78 conventional leaded packag

PBTR2040CTB Features

* Low forward volt drop

* Fast switching

* Reverse surge capability

* High thermal cycling performance

* Low thermal resistance PBYR2045CT, PBYR2045CTB series SYMBOL QUICK REFERENCE DATA VR = 40 V/ 45 V a1 1 k 2 a2 3 IO(AV) = 20 A VF ≤ 0.57 V GENERAL DE
