SAA7127H Datasheet, Encoder, NXP

SAA7127H Features

• Encoder
• Monolithic CMOS 3.3 V device, 5 V I2C-bus optionally
• Digital PAL/NTSC encoder
• System pixel frequency 13.5 MHz
• 54 MHz double-speed multiplexed D1

PDF File Details

Part number:

SAA7127H

Manufacturer:

NXP ↗

File Size:

155.54kb

Download:

📄 Datasheet

Description:

Digital video encoder. The SAA7126H; SAA7127H encodes digital Cb-Y-Cr video data to an NTSC or PAL CVBS or S-video signal. Simultaneously, RGB or bypassed b
