SC16C554D - Quad UART

Product Overview

NXP

Part number	SC16C554D
Manufacturer	NXP
File Size	254.16 KB
Description	Quad UART
Datasheet	SC16C554D Datasheet
Additional preview pages of the SC16C554D datasheet.

The SC16C554/554D is a 4-channel Universal Asynchronous Receiver and Transmitter (QUART) used for serial data communications.

of the SC16C554/554D. Some of these added features are the 16-byte receive and transmit FIFOs, automatic hardware or software ﬂow control and Infrared encoding/decoding. The selectable auto-ﬂow control feature signiﬁcantly reduces software overload and increases system efﬁciency while in FIFO mode by automatically controlling serial data ﬂow using RTS.
