TDA8310 - PAL/NTSC colour processor for PIP applications

Product Overview

NXP

TDA8310 PAL/NTSC colour processor for PIP applications by NXP - Datasheet Preview — Datasheet preview – TDA8310

Datasheet Details

Part number	TDA8310
Manufacturer	NXP
File Size	92.78 KB
Description	PAL/NTSC colour processor for PIP applications
Datasheet	TDA8310 Datasheet
Additional preview pages of the TDA8310 datasheet.

Product details

Description

plastic shrink dual in-line package; 52 leads (600 mil) GENERAL DESCRIPTION TDA8310 The TDA8310 is an alignment-free PAL/NTSC colour processor for Picture-in-Picture (PIP) applications.The circuit contains a vision IF amplifier, a PAL/NTSC colour decoder, horizontal and vertical synchronization and an RGB/YUV switch.As input for the colour decoder and sync processor the demodulated IF signal can be chosen but the circuit also has a video input which automatically detects whether the incoming

Features

Multistandard vision IF circuit (positive and negative modulation).
Video switch which automatically detects whether the incoming signal is CVBS or Y/C.
Integrated chrominance trap and bandpass filters (automatically calibrated).
Integrated luminance delay line.
Automatic PAL/NTSC decoder which can decode all standards available in the world.
Easy interfacing with the TDA8395 (SECAM decoder) for multistandard.
