UA741
DESCRIPTION
The µA741 is a high performance operational amplifier with high open-loop gain, internal pensation, high mon mode range and exceptional temperature stability. The µA741 is short-circuit-protected and allows for nulling of offset voltage.
PIN CONFIGURATION
D, F, N Packages
OFFSET NULL INVERTING INPUT 1 2 3 4 TOP VIEW
- 8 7 6 5 NC V+ OUTPUT OFFSET NULL
FEATURES
NON- INVERTING INPUT V-
- Internal frequency pensation
- Short circuit protection
- Excellent temperature stability
- High input voltage range
ORDERING INFORMATION
DESCRIPTION
8-Pin Plastic Dual In-Line Package (DIP) 8-Pin Plastic Dual In-Line Package (DIP) 8-Pin Plastic Dual In-Line Package (DIP) 8-Pin Ceramic Dual In-Line Package (CERDIP) 8-Pin Ceramic Dual In-Line Package (CERDIP) 8-Pin Small Outline (SO) Package
+
SL00095
Figure 1. Pin Configuration
TEMPERATURE RANGE -55°C to +125°C 0 to +70°C -40°C to +85°C -55°C to +125°C 0 to +70°C 0 to +70°C
ORDER CODE µA741N µA741CN SA741CN µA741F µA741CF...
