NP5004
Features
- -
- - Low Leakage Low Forward Voltage Drop Low Cost High Surge Current Capability
NP5002(R) thru NP5006(R)
Mechanical Characteristics
- -
- - Encap: Epoxy Sealed Lead: Plated Lead, Solderable Mounting: Press Fit Weight: 6.5 grams (approx.)
PRESS-FIT DIODE
Electrical Characteristics (TA = 250C unless otherwise specified) Parameter Maximum repetitive peak reverse voltage Maximum RMS Voltage Maximum DC Blocking Voltage Maximum average forward output current @ TA = 500C Peak forward surge current (8.3ms) single half sine-wave superimposed on rated load Maximum instantaneous forward voltage drop @ 100 A Maximum DC reverse TA = 250C current at rated DC TA = 1000C blocking voltage Typical Thermal Resistance Operating and storage temperature Symbol VRRM VRMS VDC IF(AV) IFSM
NP5002(R)
200 140 200 http://..net/
NP5004(R)
400 280 400 50 600
NP5006(R)
600 420 600
Units V V V A A
VF IR Rθ(j-c) TJ, TSTG
1.1 10 500 0.8 -40 to +175 o
V µA
C/W o C
D-95, Sector 63, Noida
-...
