NV6128C Datasheet, Ic, Navitas

NV6128C Features

• Ic GaNFast™ Power IC
• Large cooling pad
• Enhanced thermals when using CS resistor
• Monolithically-integrated gate drive
• Wide VCC range (10 to 30 V)

PDF File Details

Part number:

NV6128C

Manufacturer:

Navitas

File Size:

2.53MB

Download:

📄 Datasheet

Description:

650v ganfast power ic. The NV6128C is a reduced quiescent current consumption version of the popular NV6128 650 V GaNFast™ power IC, optimized for high-freq

NV6128C Application

• Applications
• AC-DC, DC-DC, DC-AC
• QR Flyback, PFC, AHB, Buck, Boost, Half bridge, Full bridge, LLC resonant, Class D
• Wi
