FAN5333A - High Current Serial LED Driver

Datasheet Summary

Description

The FAN5333A/FAN5333B is a general purpose LED driver that

Features

  • fixed frequency mode operation and an integrated FET switch. The device’s high output power makes it suitable to drive flash LEDs in serial connections. This device is designed to operate at high switching frequencies in order to minimize switching noise measured at the battery terminal of hand.
  • held communications equipment. Quiescent current in both normal and shutdown mode is designed to be minimal in order to extend battery life. Normal or shutdown mode can be selected by a logic leve.
