LA4282 - Audio Power Amplifier

Datasheet Summary

Features

High-power 2-channel AF power amplifier.
Low distortion.
Minimum number of external parts required (no bootstrap capacitor required).
Low pop noise at the time of power supply ON/OFF.
Good ripple rejection (58dB typ).
Wide operating voltage range.
External muting available.
On-chip protector against abnormality (thermal shutdown, overvoltage) Typical.
