MC74ACT574, MC74AC574 - Octal D Flip-Flop

ON Semiconductor

📥 Download Datasheet

MC74ACT574 Datasheet Preview — This datasheet PDF includes multiple part numbers: MC74ACT574, MC74AC574. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	MC74ACT574, MC74AC574
Manufacturer	ON Semiconductor
File Size	111.66 KB
Description	Octal D Flip-Flop
Datasheet	MC74AC574_ONSemiconductor.pdf
Note	This datasheet PDF includes multiple part numbers: MC74ACT574, MC74AC574. Please refer to the document for exact specifications by model.

MC74ACT574 Product details

Description

The MC74AC574/74ACT574 consists of eight edgetriggered flip flops with individual D type inputs and 3 state true outputs. flops. flops will store the state of their individual D inputs that meet the setup and hold time requirements on the LOW to HIGH Clock (CP) transition. flops are avai

Features

Inputs and Outputs on Opposite Sides of Package Allowing Easy Interface with Microprocessors.
Useful as Input or Output Port for Microprocessors.
Functionally Identical to MC74AC374/74ACT374.
3-State Outputs for Bus-Oriented.
