Part number:
MOC3083M
Manufacturer:
File Size:
345.45 KB
Description:
6-pin dip zero-cross triac driver optocoupler.
MOC3083M Datasheet (345.45 KB)
* Simplifies Logic Control of 240 VAC Power
* Zero Voltage Crossing to Minimize Conducted and Radiated Line Noise
* 800 V Peak Blocking Voltage
* Superior Static dv/dt
* 1500 V/ms Typical, 600 V/ms Guaranteed
* Safety and Regulatory Approvals
MOC3083M Datasheet (345.45 KB)
MOC3083M
345.45 KB
6-pin dip zero-cross triac driver optocoupler.
