NLV27WZ17 - Schmitt Trigger Buffer

ON Semiconductor

📥 Download Datasheet

NLV27WZ17 Datasheet Preview — Preview of NLV27WZ17 PDF

datasheet Preview Page 2

datasheet Preview Page 3

Datasheet Details

Part number	NLV27WZ17
Manufacturer	ON Semiconductor ↗
File Size	267.71 KB
Description	Schmitt Trigger Buffer
Datasheet	NLV27WZ17-ONSemiconductor.pdf

NLV27WZ17 Product details

Features

Designed for 1.65 V to 5.5 V VCC Operation.
3.7 ns tPD at VCC = 5 V (Typ).
Inputs/Outputs Overvoltage Tolerant up to 5.5 V.
IOFF Supports Partial Power Down Protection.
Sink 32 mA at 4.5 V.
Available in SC.
88 Package.
Chip Complexity < 100 FETs.
NLV Prefix for Automotive and Other.
