NSPM3042 Datasheet - ON Semiconductor

NSPM3042 - 4.8V Bidirectional ESD and Surge Protection Device

NSPM3042 4.8 V Bidirectional ESD and Surge Protection Device The NSPM3042 is designed to protect voltage sensitive components from ESD.

Excellent clamping capability, low leakage, high peak pulse current handling capability and fast response time provide best in class protection on designs that are exposed to ESD.

Because of its small size, it is suited for use in cellular phones, tablets, MP3 players, digital cameras and many other portable applications where board space comes at a premium.

Fe

NSPM3042 Features

* Low Clamping Voltage

* Low Leakage

* Small Body Outline: 1.0 mm x 0.6 mm

* Protection for the following IEC Standards: IEC61000

* 4

* 2 Level 4: ±30 kV Contact Discharge IEC61000

* 4

* 5 (Lightning) 43 A (8/20 ms)

* These Devices are

NSPM3042-ONSemiconductor.pdf

Preview of NSPM3042 PDF
NSPM3042 Datasheet Preview Page 2 NSPM3042 Datasheet Preview Page 3

Datasheet Details

Part number:

NSPM3042

Manufacturer:

ON Semiconductor ↗

File Size:

499.87 KB

Description:

4.8v bidirectional esd and surge protection device.
