NVH4L022N120M3S Datasheet, Mosfet, ON Semiconductor

NVH4L022N120M3S Features

• Mosfet
• Typ. RDS(on) = 22 mW @ VGS = 18 V
• Ultra Low Gate Charge (QG(tot) = 137 nC)
• High Speed Switching with Low Capacitance (Coss = 146 pF)
• 100% Avalanc

PDF File Details

Part number:

NVH4L022N120M3S

Manufacturer:

ON Semiconductor ↗

File Size:

442.98kb

Download:

📄 Datasheet

Description:

Sic mosfet.

NVH4L022N120M3S Application

• Applications
• Automotive On Board Charger
• Automotive DC-DC Converter for EV/HEV MAXIMUM RATINGS (TJ = 25°C unless otherwise note
