* Small Footprint (5x6 mm) for Compact Design
* Low RDS(on) to Minimize Conduction Losses
* Low QG and Capacitance to Minimize Driver Losses
* NVMFS5C430NWF
* Wettable Flank Option for Enhanced Optical Inspection
* AEC
* Q101 Qualified and PPAP Capable
* These D
NVMFS5C430N Datasheet (273.98 KB)
NVMFS5C430N
273.98 KB
N-channel power mosfet.
DATA SHEET www.onsemi.com
MOSFET - Power, Single N-Channel, DFN5/DFNW5
40 V, 1.7 mW, 185 A
NVMFS5C430N
V(BR)DSS 40 V
RDS(ON) MAX 1.7 mW @ 10 V
ID .
