SA20CA Datasheet - ON Semiconductor

SA20CA Zener Transient Voltage Suppressors

SA5.0CA Series 500 Watt Peak Power MiniMOSORB™ Zener Transient Voltage Suppressors Bidirectional The SA5.0CA series is designed to protect voltage sensitive components from high voltage, high energy transients. They have excellent clamping capability, high surge capability, low zener impedance and fast response time. The SA5.0CA series is supplied in ON Semiconductor’s exclusive, cost-effective, highly reliable Surmetict axial leaded package and is ideally-suited for use in communi.

SA20CA Features

* Working Peak Reverse Voltage Range

* 5.0 to 170 V

* Peak Power

* 500 Watts @ 1 ms

* ESD Rating of Class 3 (>16 KV) per Human Body Model

* Maximum Clamp Voltage @ Peak Pulse Current

* Low Leakage < 1 mA above 8.5 V

* UL 497B for Isola

SA20CA Datasheet (170.03 KB)
