UESD12ST5G

ESD Protection Diodes

UESD12ST5G Features

* ăSmall Body Outline Dimensions: 0.055″ x 0.024″ (1.40 mm x 0.60 mm)

* ăLow Body Height: 0.020″ (0.5 mm)

* ăStand-off Voltage: 3.3 V - 12 V

* ăLow Leakage

* ăResponse Time is Typically < 1 ns

* ăESD Rating of Class 3 (> 16 kV) per Human Body Model

UESD12ST5G Datasheet (75.28 KB)

Preview of UESD12ST5G PDF

Datasheet Details

Part number:

UESD12ST5G

Manufacturer:

ON Semiconductor ↗

File Size:

75.28 KB

Description:

Esd protection diodes.
mESD3.3ST5G SERIES ESD Protection Diodes In Ultra Small SOD-723 Package The mESD Series is designed to protect voltage sensitive components from ESD..
