MMUN2114LT1 PNP SILICON BIAS RESISTOR TRANSISTOR

MMUN2111LT1 Series Preferred Devices Bias Resistor Transistors PNP Silicon Surface Mount Transistors with Monolithic Bias Resistor Network This new series of digital transistors is designed to replace a single device and its external resistor bias network. The BRT (Bias Resistor Transistor) contains a single transistor with a monolithic bias network consisting of two resistors; a series base resistor and a base-emitter resistor. The BRT eliminates these individual components by integrating them.

MMUN2114LT1 Features

* Simplifies Circuit Design

* Reduces Board Space

* Reduces Component Count

* The SOT-23 package can be soldered using wave or reflow. The modified gull-winged leads absorb thermal stress during soldering eliminating the possibility of damage to the die.

* Ava

MMUN2114LT1 Datasheet (106.74 KB)
