Description
2 system level description
2.1 overview 2.2 architecture 2.3 format and frame 2.4 I/O control 2.5 MIPI interface 2.6 power management
2.6.1 power up sequence 2.6.2 power down sequence 2.7 reset 2.7.1 power ON reset 2.7.2 software reset 2.8 hardware and software standby 2.8.1 hardware standby 2.8.2 software standby 2.9 system clock control 2.9.1 PLL1 2.9.2 PLL2 2.10 serial camera control bus (SCCB) interface 2.10.1 data transfer protocol 2.10.2 message format 2.10.3 read / write operation 2.10.4
Features
- 1.12 µm x 1.12 µm pixel with OmniBSI-2™ technology
optical size of 1/4"
32.9° CRA for ~4mm Z-height
programmable controls for frame rate, mirror and flip, cropping, and windowing
supports images sizes: 8MP(4:3 - 3264x2448), 8MP (16:9 - 3264x1836), EIS 1080p (2112x1188), 1080p (1920x1080), EIS 720p (1408x792), and more
8MP at 30 fps
two-wire serial bus control (SCCB)
frame exposure mode for still image (with mechanical shutter)
4k bits of embedded one-time programmable (OTP) me.
