SPTP15R7D5
Features
- Proprietary New Trench Technology
- RDS(ON),typ.=4.95mΩ@VGS=10V
- Low Gate Charge Minimize Switching Loss
- Fast Recovery Body Diode
BVDSS 150V
RDS(ON),typ. 4.95mΩ
ID[2] 150A
Applications
- DC/DC Converter
- Motor Control
- Synchronous Rectification in SMPS
Ordering Information
Part Number Package
TO-220
Brand
TO-220 Package Not to Scale
Absolute Maximum Ratings
TC=25℃ unless otherwise specified
Symbol
Parameter
Unit
VDSS VGSS
IDM EAS dv/dt
TL TPAK
Drain-to-Source Voltage[1]
Gate-to-Source Voltage Continuous Drain Current[2] Continuous Drain Current @ Tc=100℃[2] Pulsed Drain Current at VGS=10V[2,3] Single Pulse Avalanche Energy L=1m H
Peak Diode Recovery dv/dt
Power Dissipation Derating Factor above 25℃ Maximum Temperature for Soldering Leads at 0.063in (1.6mm) from Case for 10 seconds, Package Body for 10 seconds
150 ±20 150 100 560 1600 5.0 266 2.13
300 260
A m J V/ns
W W/℃
℃
TJ& TSTG
Operating and Storage Temperature...
