PT5139A Datasheet - PTC

Dual H-Bridge Motor Driver

PT5139A Features

* includes under-voltage lockout (UVLO), over current protection (OCP) and thermal shutdown (TSD). A fault flag output is available to indicates the OCP or TSD conditions is happens. APPLICATIONS

* POS Printers

* Video Security Camera

* Robotics

* Battery Powered Toys PT5139A Dual H-

PT5139A General Description

The PT5139A is a dual H-bridge motor driver which can drives two brushed DC motors or a single bipolar stepper motor, solenoids or other inductive loads. Each bridge driver includes a PWM current regulation circuitry to limit the winding current. The H-bridge driver is consists by all of N-channel M.

PT5139A Datasheet (740.75 KB)

PT5139A Datasheet Preview — Preview of PT5139A PDF

Datasheet Details

Part number:

PT5139A

Manufacturer:

PTC

File Size:

740.75 KB

Description:

Dual h-bridge motor driver.
