RS2596 Datasheet - PTC

3A PWM Buck DC/DC Converter

RS2596 Features

* include a guaranteed 4% tolerance on output voltage under specified input voltage and output load conditions, and 15% on the oscillator frequency. Regarding protected function, thermal shutdown is to prevent over temperature operating from damage, and current limit is against over current operating

RS2596 General Description

The RS2596 is Monolithic IC that design for a step-down DC/DC Converter, and own the ability of driving a 3A load without additional transistor component. The output version included 3.3V, 5V, 12V and an adjustable type. It operates at a switching frequency of 150KHz thus allowing smaller sized filt.

RS2596 Datasheet (298.80 KB)

RS2596 Datasheet Preview — Preview of RS2596 PDF

Datasheet Details

Part number:

RS2596

Manufacturer:

PTC

File Size:

298.80 KB

Description:

3a pwm buck dc/dc converter.
