AN5101NSC Datasheet PDF - Panasonic VIF / SIF IC Specs

AN5101NSC - VIF / SIF IC

Datasheet Summary

Description

Pin No.

1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 Description Supply pin VCC1 (AFC output use) AFC output pin VIF AGC filter pin Supply pin VCC2 (for main) RF AGC delay adjustment pin VIF input pin VIF input pin GND pin (for main) QIF input pin QIF input pin N.C.

Features

w w The AN5101NSC is a VIF/SIF signal processing IC for TV and VCR. Reduction of sound noise and improvement of picture quality have been realized by adoption of the gated PLL detection system.
Reduction of buzz-beat (sound noise) when receiving for sound multiplex broadcasting service.
Improvement of video over-modulation characteristics.
Built-in equalizing amplifier which enables the correction of video frequency characteristics.
Low power consumption (5.

Datasheet Details

Part number	AN5101NSC
Manufacturer	Panasonic
File Size	85.91 KB
Description	VIF / SIF IC
Datasheet	AN5101NSC Datasheet
Additional preview pages of the AN5101NSC datasheet.

📁 Similar Datasheet

AN5111 - Color TV Video IF Amplifier / Detector / AGC and AFC Circuit (Matsushita Electric)

AN5112 - Color TV VIF and SIF Circuit (Matsushita Electric)

AN5122 - Color TV Video IF Amplifier / Detector / AGC / AFC Circuit (Matsushita Electric)

AN5125 - Color TV Video IF Amplifier / PLL Detector / AGC / AFC Circuit (Matsushita Electric)

AN5130 - COLOR TV IF AMPLIFIER DETECTOR AGC/ AFC CIRCUITS (ETC)

AN5132 - COLOR TV IF AMPLIFIER DETECTOR AGC/ AFC CIRCUITS (ETC)

AN5136K - Color TV Video IF Amplifier / PLL Detector (Matsushita Electric)

AN5138NK - Video IF Amplifier / PLL Detector (Panasonic Semiconductor)

AN5150N - IC for TV Large Integration (Panasonic Semiconductor)

AN5151 - TV VIF & SIF & DEFLECTION SYSTEM (Unisonic Technologies)

Full PDF Text Transcription

Click to expand full text

ICs for TV 1.23 0.35±0.1 s Applications • TV and VCR s Block Diagram AFC w V-set. w Sync. sep. w .D 28 RF AGC delay 5 t a 26 NI 27 Video out 18 VCO GND 21 VCO V CC S a 25 e h 23 t e 22 Seating plane SSOP032-P-0375 U 4 1.0 20 19 0.1±0.1 0.9 2.0±0.2 AN5101NSC com . VIF/SIF IC for TV andU VCR 4 t e s Overview e h S a t a D . w s Features w w The AN5101NSC is a VIF/SIF signal processing IC for TV and VCR. Reduction of sound noise and improvement of picture quality have been realized by adoption of the gated PLL detection system.
