MA133 - Silicon epitaxial planar type Switching Diodes

Panasonic

Datasheet Details

Part number	MA133
Manufacturer	Panasonic
File Size	226.43 KB
Description	Silicon epitaxial planar type Switching Diodes
Datasheet	MA133_PanasonicSemiconductor.pdf

s.
Two isolated elements contained in one package, allowing high- density mounting.
Two diodes are connected in series in the package.
Absolute Maximum Ratings Ta = 25°C Parameter Symbol Rating Reverse voltage Maximum peak reverse voltage Forward current Single Series VR VRM IF 80 80 100 65 Peak forward current Single Series IFM 200 130 Junction temperature Storage temperature Tj 150 Tstg.
55 to +150 Unit V V mA mA °C °C stage. dc (0.44)e (0.375) (0.
