MA7D49A Datasheet, Diode, Panasonic

MA7D49A Features

• Diode φ 3.2±0.1 15.0±0.5
• Low forward voltage VF
• High dielectric breakdown voltage: > 5 kV
• Easy-to-mount, due to its V cut lead end 1.4±0.2 1.6±0.2 2.6±0.1

PDF File Details

Part number:

MA7D49A

Manufacturer:

Panasonic

File Size:

214.33kb

Download:

📄 Datasheet

Description:

Schottky barrier diode.

MA7D49A Application

• Applications or general electronic equipment (such as office equipment, communications equipment, measuring instruments and household appliances). C
