74F365 Datasheet - Philips

74F365 Buffers/drivers

16-pin plastic DIP 16-pin plastic SO VCC = 5V ±10%, 10% Tamb = 0°C to +70°C N74F365N, N74F367N N74F365D, N74F367D PKG DWG # SOT38-4 SOT109-1 INPUT AND OUTPUT LOADING AND FAN-OUT TABLE PINS I0 - I5 OE0, OE1 DESCRIPTION Inputs Output enable inputs (active Low) 74F(U.L.) HIGH/LOW 1.0/0.033 1.0/0.033 L.

74F365 Features

* 74F365, 74F366

* 74F367, 74F368

* High-impedance NPN base inputs for reduced loading (20µA in High and Low states) TYPE 74F365, 74F367 74F366, 74F368 TYPICAL PROPAGATION DELAY 5.0ns 5.0ns TYPICAL SUPPLY CURRENT (TOTAL) 36mA 33mA

* High-speed

* Bus oriented
