TDA9552PS, TDA956X - TV signal processor

Philips

TDA9552PS Datasheet Preview — This datasheet PDF includes multiple part numbers: TDA9552PS, TDA956X. Please refer to the document for exact specifications by model.

Datasheet Details

Part number	TDA9552PS, TDA956X
Manufacturer	Philips ↗
File Size	520.30 KB
Description	TV signal processor
Datasheet	TDA956X_Philips.pdf
Note	This datasheet PDF includes multiple part numbers: TDA9552PS, TDA956X. Please refer to the document for exact specifications by model.

TDA9552PS Product details

Description

The various versions of the TDA955X/6X/8X PS/N1 series combine the functions of a video processor together with a µ-Controller and US Closed Caption decoder.

Features

e Caption.
Serial and Parallel Display Attributes.
Single/Double/Quadruple Width and Height for characters.
Scrolling of display region.
Variable flash rate controlled by software.
Enhanced display features including overlining, underlining and italics.
Soft colours using CLUT with 4096 colour palette.
Globally selectable scan lines per row (9/10/13/16) and character matrix [12x10, 12x13, 12x16 (VxH)].
Fringing (Shadow) sele.
