NE56631-29D Active-LOW system reset

The NE56631-XX is a family of Active-LOW, power-on resets that offers precision threshold voltage detection within ±3% and super low operating supply current of typically 1.5 µA. Several detection threshold voltages are available at 1.9 V, 2.0 V, 2.7 V, 2.8 V, 2.9 V, 3.0 V, 3.1 V, 4.2 V, 4.3 V, 4.4 .

NE56631-29D Features

* High precision threshold detection voltage:

* Super low operating supply current: ICCH=1.5 µA typ.; ICCL=1.0 µA typ. APPLICATIONS VS ±3%

* Hysteresis voltage: 50 mV typ.

* Internal Power-On-Reset Delay time: 20 µs typ.

* Detection threshold voltage: 1.9 V

NE56631-29D Datasheet (107.84 KB)
