www.DataSheet4U.com Connecting the Units Note: This unit is for vehicles with a 12-volt battery and negative grounding. Before installing it in a recreational vehicle, truck, or bus, check the battery voltage. To avoid shorts in the electrical system, be sure to disconnect the ≠ battery cable before beginning installation. Refer to the owner’s manual for details on connecting the power amp and other units, then make connections correctly. Secure the wiring with cable clamps or adhesiv.

DEH-1100 Features

* a glass antenna, connect to the antenna booster power supply terminal. When an external power amp is being used with this system, be sure not to connect the blue/white lead to the amp’s power terminal. Likewise, do not connect the blue/white lead to the power terminal of the auto-antenna. Such conne
