QLA764B-HGY
DESCRIPTION
For right-angle and vertical viewing, the QT Optoelectronics LED circuit board indicators e in T-3/4, T-1 and T-1 3/4 lamp sizes, and in single, dual and multiple packages. The indicators are available in AIGa As red, high-efficiency red, bright red, green, yellow, and bi-color at standard drive currents, as well as at 2 m A drive current. To reduce ponent cost and save space, 5 V and 12 V types are available with integrated resistors. The LEDs are packaged in a black plastic housing for optical contrast, and the housing meets UL94V-0 flammability specifications.
.099 (2.52) .093 (2.36)
+
.143 (3.63)
.250 (6.35)
+
.125 (3.18)
DENOTES ANODE LEAD .300 (7.62) .029 MAX (0.74) .100 (2.54) .500 (12.70)
FIG.
- 1
.099 (2.52) .093 (2.36) .125 (3.18) .250 (6.35)
.200 (5.08) .045 (1.14) DENOTES ANODE LEAD
T-3/4 (Subminiature)
PART NUMBER MV5000.MP1 MV5300.MP1 MV5400.MP1 COLOR RED YLW GRN RED YLW GRN RED YLW GRN VF 1.7 2.1 2.3 1.7 2.1 2.3 1.7 2.1 2.3 5.0 5.0 5.0 5.0 5.0 5.0 5.0...
